4-10 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Main Menu
Structure
Operation of the D9858 Advanced Receiver Transcoder begins at the Main menu.
From the startup screen, press the MENU key to view the Main menu.
Menu Selection
Select the desired function by moving the cursor left or right by pressing the LEFT
or RIGHT arrow key. Once a selection is made by pressing the SELECT key, the
LCD presents the second menu level for the selected function. Succeeding levels for
each function include all the heirachical levels for the function in the front panel
LCD. For example, the TS Input level is shown as Main: Setup: TS Input, with each
succeeding level separated by a colon (:), as shown in the example below. The front
panel menus are described on the following pages.
Main Menu 1/2
Status Setup About Versions
i
s
Main Menu 2/2
Diagnostics
i
s
Main Menu 1/2
Status Setup About Versions
i
s
Main:Status
General Services TS Input TS Output
i
s
Main:Setup 1/2
Admin TS Input IP Services
i
s
Main:Setup 2/2
Outputs CA Alarm/Warning NoiseCutoff
i
s
Main:Setup:TS Input
Input Tune Mode
i
s
2
nd
level
3
rd
level
1
st
level
To Next Page
