4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-57
Setup Menu: Outputs: TS Out: DPM
Structure
To view the DPM menu from the TS Out menu, press the RIGHT arrow key twice.
The DPM menu provides access to functionality associated with Global and ASI
and MOIP1 outputs.
The DPM menu allows you to groom functionality on a program basis where
individual service PID modifications are provided on a limited scale.
Use the digital program mapping features to:
• configure the transport output bit rate
• configure the output mode for a program entry
• configure the service and PID output settings in a program entry
The DPM menu has the following structure:
PE InCh PMT Act OutCh PMT PID
PE1 65535 8191 Map 65535 8191
i
s
InTyp In PID Act OutType In PID
UNKN 04 1234 Map UNKNxFF 05 1234
i
s
PE Resync: All Template PIDs Svcs
PE1
i
s
Main:Setup:Outputs:TS Out:DPM
Global ASI MOIP1
PAT CAT PMT TSDT NIT NITO
Regen Regen Regen Drop Regen Drop
i
s
SDT SDTO BAT EIT TDT RST
Regen Drop Drop Drop Drop Drop
i
s
TOT DIT SIT ECM EMM DRT CDT
Drop Drop Drop Drop Drop Drop Drop
i
s
Map Mode Duplic Mode Unref
Svc ID & PID PSI Remap Drop
i
s
PSI Options PSI Rate Service ID
Ctl By Table MPEG Min Valid Ch
i
s
ASI
PE InCh PMT Act OutCh PMT PID
PE1 65535 8191 Xcode 65535 8191
i
s
PE Resync: All Template PIDs Svcs
PE1
i
s
PAT CAT PMT TSDT NIT NITO
Regen Regen Regen Drop Regen Drop
i
s
SDT SDTO BAT EIT TDT RST
Regen Drop Drop Drop Dro Drop
i
s
TOT DIT SIT ECM EMM DRT CDT
Drop Drop Drop Drop Drop Drop Drop
i
s
Map Mode Duplic Mode Unref
Svc ID & PID PSI Remap Drop
i
s
PSI Options PSI Rate Service ID
Ctl By Table MPEG Min Valid Ch
i
s
MOIP1
Global
Resync All: ASI MOIP1
i
s
Copy: ASI->MOIP1 MOIP1->ASI
i
s
InTyp In PID Act OutType In PID
UNKN 04 1234 Xcode UNKNxFF 05 1234
i
s
i
s
