4-6 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Startup Screen
Menu Structure
On power-up and initialization, the startup screen is displayed similar to that
shown below. The screen also indicates the signal status.
Startup Screen Channel Authorization Status Screen
Channel Authorization Status
From the startup screen, press the right or left arrow keys on the front panel keypad
to move to the PE entry authorization status screen. This screen indicates whether
the decode channel and other selected channels are authorized.
LCD Panel
The LCD panel displays basic signal and program information in the LCD display,
as described in the following illustration:
s
PE1 12345 Channel Name
RF1 Freq:12.658 Lvl:100 Marg:9.9e-9
PE: 1 2
Auth:Y Y
Auth Status Description
Y Indicates the channel is authorized.
N Indicates the channel is not authorized.
LCD Setting Description
PE PE. The transcoder supports two Program Entries (PE1 and
PE2). PE1 is the decode channel and is available at the
analog outputs. PE2 is available for the second transcoded
channel on the ASI output.
12345 Channel for program monitoring.
Channel name Name of the monitored program.
s
PE1 12345 Channel Name
RF1 Freq:12.658 Lvl:100 Marg:9.9e-9
Hourglass
