1-6 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Input/Output Settings
Proceed as follows to configure the Video output format and TS Output settings:
1. Press the MENU key and use the RIGHT arrow key to navigate to the Setup:
Services: Video menu, using the SELECT key to move down each level, and
then use the arrow keys to navigate and set the video output format.
2. Press MENU to exit the menu level and save the changes.
3. Use the arrow key to move to the Setup: Outputs: TS Out: ASI or MOIP1
menu, using the SELECT key to move down each level, and then use the
arrow keys to navigate and configure the Output Mode. Refer to DPM
Default Settings for Different Output Modes, page B-9 for information on the
default settings for each output mode, to choose the desired Output Mode.
4. Press MENU to exit the menu level and save the changes.
Entry/Selection Options
SD Format Set to Auto (default) or the particular output resolution
for the monitor, e.g., NTSC or PAL.
Entry/Selection Options
Output Mode It is recommended to set the Output Mode to
Transcoding. The output mode is factory set to No
Output as the default.
Resync All Resynchronize the output services, ASI or MOIP1.
Select Yes when prompted.
