B-2
Model D9858 Advanced Receiver Transcoder
Installation and Operation
Guide
4023074 Rev B
Factory Default Settings
RF Tuning
Tune Mode
Parameter
Default
RF Sel
RF1
Freq
3.449
Sym Rate
28.3465 MSps
FEC
AUTO
Polarity
Horiz
IQ
AUTO
LO1
5.15 GHz
LO2
0
LO Sel
Off
XOVER
0.0
Polarization
Horiz
Orb Pos
0
.0
LNB Power
Off
East/West
NA
Modulation DVB-S
DVB-S2 Roll-off
0.35
Parameter
Default
Acq Mode
Basic
CA Mode
Std
Freq Sel
NIT
Service List
Rigorous
Use BAT
No
Use NIT
No
Use SDT
No
Use PAT
No
183
185
Table of Contents
Safety Precautions
5
Règles de Sécurité
10
Sicherheitsvorkehrungen
11
Precauciones de Seguridad
12
Precauzioni DI Sicurezza
13
Important Safety Instructions
14
Table of Contents
21
About this Manual
25
Chapter 1 Quick Setup - Read Me First
27
Connecting the Transcoder
27
Front Panel Setup
29
Setting up TS Input and Tuning
30
Assigning a Program Channel to a Program Entry
31
Input/Output Settings
32
Chapter 2 Introduction
33
D9858 Advanced Receiver Transcoder
34
Transport Stream Outputs
36
Control and Management Interfaces
37
Chapter 3 Installation
39
Section a - Rack Installation
40
General
40
Installing the D9858 Advanced Receiver Transcoder
41
Section B - Rear Connector Panel
43
Overview
43
Section C - Connecting the Input/Output Signals
45
Connecting the RF Inputs
45
Connecting the ASI Input
45
Section D - Connecting the Input/Output Signals
46
Connecting the Video Outputs
46
Connecting the Audio Outputs
47
Connecting the Ethernet Management Interface
48
Connecting the IP TS Output
49
Connecting the ASI Outputs
50
Connecting an External Alarm System
51
Connecting the RS-232 Data Interface
52
Chapter 4 Front Panel Operation
53
About the Front Panel
54
Keypad Convention
56
Startup Screen
58
Main Menu
62
Status Menu
63
Status Menu: General
64
Status Menu: Services
66
Status Menu: TS Input
68
Status Menu: TS Output
72
Setup Menu
73
Setup Menu: Admin
74
Setup Menu: TS Input
79
Setup Menu: TS Input: Input: ASI
80
Setup Menu: TS Input: Input: RF1-RF4
81
Setup Menu: TS Input: Tune Mode: Custom
84
Setup Menu: IP
86
Setup Menu: Services
89
Setup Menu: Services: Video
90
Setup Menu: Services: Audio
94
Setup Menu: Services: Captions
95
Setup Menu: Services: Subtitles
96
Setup Menu: Services: Decode
99
Setup Menu: Outputs
100
Setup Menu: Outputs: TS out
101
Setup Menu: Outputs: TS Out: ASI, Continued
102
Setup Menu: Outputs: TS Out: DPM
109
Setup Menu: Outputs: TS Out: Transcode
120
Setup Menu: CA
124
Setup Menu: Alarm/Warning
127
Setup Menu: Noise Cutoff
129
About Menu
133
Versions Menu
135
Diagnostics Menu: PSI
138
Diagnostics Menu: PSI, Poweron, Health Monitor
139
Chapter 5 Service and Maintenance
141
Section a - Front Panel Leds
142
Introduction
142
Messages
144
Section B - Power Supply Replacement
159
Introduction
159
Chapter 6 Customer Information
161
Product Support
162
Returning Products
164
Appendix A Technical Specifications
167
Section a - L-Band Input and Processing
171
General
171
LNB lo Stability
171
LNB Power and Control
171
Dvb-S/Dvb-S2
172
Section B - Video Inputs/Outputs and Processing
175
General
175
Video Inputs
175
Video Outputs
175
Audio Inputs/Outputs
178
VBI Data Input/Output
178
Section C - Transport Stream Outputs
179
ASI Output
179
Mpegoip Output
179
Section D - Control and Management Interfaces
180
Ethernet Management Interface
180
RS-232 Data Interface
180
Alarm Interface
180
Contact Closure Interface
180
Section E - Power and General Specifications
181
General
181
Power
181
Section F - Mechanical/Environmental
182
Mechanical
182
Environment
182
Appendix B Default Settings
183
Factory Default Settings
184
DPM Default Settings for Different Output Modes
191
Appendix C Lock Levels
195
D9858 Advanced Receiver Transcoder Lock Levels
196
Appendix D Equipment and Accessories
211
Accessory Kits for the D9858 Advanced Receiver Transcoder
212
Appendix E Compliance
213
Applicable Standards and Notices
214
