Setup Menu: Services
Structure
To view the Services menu from the Main menu, press the RIGHT arrow key once
and then the SELECT key to reach the Setup menu. Then press the RIGHT arrow
key three times and the SELECT key to view the Services menu.
The Services menu allows you to setup all the operating parameters associated with
audio, video, captions and VBI services. This affects the decode channel (PE1) only
and not the transcode channel.
Each parameter is described below. The menu has the following structure:
VIDEO
PV Format
Description: Selects the output video format.
Parameters: Fixed at SD.
Audio
Captions
Video
WSS Mode WSS Status
Passthrough 16:9 F/F
i
s
Preferred Mode Actual Output
Auto EIA 708
i
s
Aud# Stereo/Mono AC3 Compression
1 Stereo Line Mode
i
s
Aud# Left(dB) Right(dB)
1 -6.0 -6.0
i
s
Audio Decoder Aud1 Aud2
PMT Audio Source 1 2
i
s
Main:Setup:Services 1/2
Video Audio Captions
i
TV A/R Convert Stream Act Conv
16:9 16:9 F/W 16:9 16:9 F/W
i
s
SD Format SD Output Bitrate
Auto NTSC 19.5648
i
s
PV Format PV Output Stream
Auto HD1080i SD480i/2997
i
s
Subtitles
Decode
Decoder Enabled
Audio1 Yes
i
s
Op Mode Select Language By
Off Language List
i
s
Language List PMT Order Entry
eng First eng
i
s
Imitext Position ForeGnd BackGnd
Standard Auto Auto
Main:Setup:Services 2/2
Subtitles Decode
i
s
i
s
