4023074 Rev B D9858 Advanced Receiver Transcoder Installation and Operation Guide 1-5
Assigning a Program Channel to a Program Entry
Proceed as follows to assign program channels to program entries:
1. Set up the two Program Entries, PE1 and PE2, for two input program channels
that you are authorized to receive. See Assigning Programs to Program Entries
for more information.
2. Press MENU until you display the startup screen.
PE1 (the decode Program Entry) is initially displayed.
3. Press the ADV key on the front panel keypad and then the arrow keys to
scroll through the two PEs available.
4. Press the SELECT key to select a PE (PE1 or PE2) and then the use arrow
key to move to the right and scroll through the available program channels.
5. Directly enter the channel number for the selected PE using the 0 to 9 keys, and
press SELECT to save the channel selection.
6. Repeat this process to select a program channel for PE2.
s
PE1 1 Channel Name
RF1 Freq:12.658 Lvl:100 Marg:9.9e-9
PE Ch #
