4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide A-7
Section B - Video Inputs/Outputs and Processing
General
Video Inputs
Video Outputs
Item Specification
System MPEG-2/DVB Compatible
EN 300 421, EN 300 468
Item Specification
Transcoder Channel Inputs
HD Video Input
Number of Channels 1
Compression Format MPEG-4 AVC
V Resolutions 1080, 720
Horizontal Video Resolutions 1080i: 1920, 1440
720p: 1280, 960
Bit Rate 3 Mb/s to 20 Mb/s Main Profile
3 Mb/s to 25 Mb/s High Profile
Connector BNC, 75 Ω
Item Specification
Transcoder Channel Outputs
HD Video Output
Number of Channels One
Compression Format MPEG-2
Vertical Resolutions Same as input.
Horizontal Resolutions 1080i : 1920, 1440
720p: 1280, 960
Bit Rate 10 to 25 Mb/s
