A-6 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
DVB-S/DVB-S2, Continued
DVB-S2 Error Rate Performance Es/No (C/N) Ratio
Note: The “Typical Performance” results are valid if the LNB phase noise is within
the specified range.
Mode Ideal Es/No (dB) for FEC
Frame length = 64,800
Typical Performance (dB)
BW = Symbol Rate
QPSK 1/2 1.00 1.2
QPSK 3/5 2.23 2.4
QPSK 2/3 3.10 3.2
QPSK 3/4 4.03 4.2
QPSK 4/5 4.68 4.8
QPSK 5/6 5.18 5.3
QPSK 8/9 6.20 6.4
QPSK 9/10 6.42 6.6
8PSK 3/5 5.50 5.8
8PSK 2/3 6.62 6.8
8PSK 3/4 7.91 8.1
8PSK 5/6 9.35 9.6
8PSK 8/9 10.69 10.9
8PSK 9/10 10.98 11.3
