3-6 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
RS-232 Data RS-232 data output: 7 bits, even
parity, 1 stop bit, up to 38.4 kbps.
These outputs are user-configurable
via the Setup menu on the front
panel.
9-pin sub-D female
Composite Video
Outputs
CVBS 1 and CVBS 2 provide two
identical SD composite video
outputs for monitoring applications.
BNC
Balanced Audio
Outputs
Audio 1 and Audio 2 provide two
stereo pairs or four mono channels.
Terminal Blocks
Gnd Screw Grounding point for
the transcoder.
Power AC power IEC 60320 Sheet 14
Connector
Function Connector Type
To Next Page
