4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 5-3
SIGNAL
Green Solid indicates all of the following conditions:
• all RF inputs are enabled, all inputs are locked to a
signal, and are not muted.
• all outputs are operating without an error.
Green Flashing indicates one of the following conditions:
• difficulty with an input or output.
• one or more RF inputs, or the ASI input are not
synchronized.
• one or more outputs are muted by a fault condition.
• the receiver is not authorized to receive the program.
• no RF signal is present or detected, or it is muted.
Off Off indicates all of the following conditions:
• no RF input signal is available, enabled or detected, or
the input is muted.
• no ASI input is present.
• no valid inputs are available.
LED Signal
State/Color
Explanation
