Cisco PowerVu D9858 User Manual

B-10 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
DPM Default Settings for Different Output Modes, Continued
The fields labelled “Any” in the table below, are ‘don’t care’ parameters, in which
case, the Output Mode will not change if the parameter is changed. However, if you
change any of the other parameters listed in the table for the MAP or Transcoding
output modes, the Output Mode will change to Full DPM Control.
Output
Mode
No Output Passthrough Service
Chans Only
MAP
Passthrough
MAP Svc
Chans Only
Transcoding
Rate Control Any Any Any Any Any Any
User Rate Any Any Any Any Any Any
Descramble
Mode
Any Any Any Any Any Descrambled
Regenerate Any Any Any Any Any Any
Insert Null
Packet
Any Any Any Any Any Any
Map Mode Svc ID Svc ID Svc ID Svc ID & PID Svc ID & PID Svc ID & PID
Duplic
Mode
PSI Remap PSI Remap PSI Remap PSI Remap PSI Remap Pkt Copy
Unref Drop Pass Drop Pass Drop Drop
PSI Options Drop Ctl By Table Ctl By Table Ctl By Table Ctl By Table Ctl By Table
PSI Rate SA Std SA Std SA Std SA Std SA Std SA Std
Svc ID Valid Ch Valid Ch Valid Ch Valid Ch Valid Ch Valid Ch
PAT Pass Pass Regen Regen Regen Regen
CAT Pass If Descramble
Mode is set to
Descrambled,
it is set to
Regen;
otherwise, it is
set to Pass
If Descramble
Mode is set to
Descrambled,
it is set to
Regen;
otherwise, it
is set to Pass
Regen Regen Regen
PMT Pass If Descramble
Mode is set to
Descrambled,
it is set to
Regen;
otherwise, it is
set to Pass
If Descramble
Mode is set to
Descrambled,
it is set to
Regen;
otherwise, it
is set to Pass
Regen Regen Regen
TSDT Pass Pass Pass Pass Pass Pass
NIT Pass Pass Regen Regen Regen Regen
NITO Pass Pass RwRC PwRc PwRC PwRC
