4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-15
Status Menu: Services, Continued
BR
Description: Indicates the audio bit rate of the received audio channel.
Parameters: Kbps.
Buffer
Description: Indicates the audio input buffer level.
Parameters: bytes.
SFR
Description: Indicates the audio sampling frequency.
Parameters: 32, 44.1 or 48 kHz.
TS INPUT
INPUT
Input
Description: Indicates the active input port receiving the signal.
Parameters: RF1, RF2, RF3, RF4 or ASI.
Status
Description: Indicates the current signal lock status for the input.
Parameters: Signal Lock - see table.
Rate
Description: Indicates the bit rate of the received input signal.
Parameters: Mbps.
Level
Description: Indicates the signal level of received signal.
Parameters: dBm.
Status Description
Locked Indicates the transcoder is locked to a
carrier with no valid content.
Lock+Sync Indicates the transcoder is locked to a
carrier with valid content.
No Lock Indicates the transcoder is not locked to a
carrier.
