Cisco SPA525G User Manual

6
Cisco Small Business Pro IP Phone SPA525G (SIP) User Guide 97
Using the SPA932 Attendant Console
This chapter describes how to install and use the SPA932 Attendant Console with
your SPA525G IP Phone.
Figure 1 SPA932 Attendant Console
The SPA932 is a 32-button attendant console for the SPA525, providing 32 three-
color (red, green, and orange) programmable LEDS, with support for Broadsoft
Busy Lamp Field and Asterisk Line Monitoring. The SPA932 attaches to the
SPA525 with the attachment arm provided. It obtains power directly from the
SPA525 and does not require a separate power supply. Two SPA932 units can be
attached to a single SPA525 to monitor a total of 64 separate lines.

Cisco SPA525G Specifications

General

Lines	5 lines
Protocols	SIP, SPCP
Power	Power over Ethernet (PoE) or AC adapter
Speakerphone	Yes
Connectivity	Bluetooth
Audio	Wideband audio
USB	USB 2.0 port
Ethernet Ports	2 x 10/100 Mbps
Codecs	G.711, G.729, G.722
Display	3.2 inch QVGA (320 x 240 pixels) color LCD
