Parameter
Description
Wireless channel
There are two setting options:
• Auto The corresponding channel is automatically searched for.
•
The channels are unlocked and can be selected manually.
<Scan channels>
Scan radio channel. The button is not active if a channel is selected at Wire-
less channel.
Transmit power
Set transmission power.
Roaming Aggressiveness
Setting option, from which signal strength the tool connects with another ac-
cess point.
<OK>
Exit the input window, the settings are saved.
<Cancel>
Exit input window, the settings are not saved.
7. Confirm settings with <OK>.
8. Press <Apply>.
 Settings are written onto the tool.
9. Confirm the following message with <Yes>:
Toolserial: xxxxxxx
Builddate: xx.xx.xx
Configure Tool?
10. Confirm the following message with <OK>:
Configuration done!
11. Installing the tool on the controller.
4.3 Installing the Tool
Up to ten tools can be connected to one controller via WLAN.
Up to seven tools can be connected to one controller via Bluetooth.
1. Select Navigator> Tool Setup on the user interface of the controller.
2. Press <Install> to add a tool to the tool list.
3. Carry out the following settings:
Parameter
Description
Group Name
► Select Tool Group.
Name
► Select Tool Group.
Type
► Select CellClutch.
IP address / hostname
► Enter the IP address that has been assigned to the tool using the
LiveWire Utilities software.
4. Press <OK> and save the settings.
 The Tool List is displayed.
 Status of tool is now Needs User Acceptance..
5. Select <Tool Settings>.
6. Check the Model Number and Serial Number and confirm that the tool displayed corresponds to the
tool connected.
7. Save the settings with <Accept>.
 The Tool List is displayed. Status of tool is now Online.
8. To save the settings, select <Navigator>.
9. For additional programming for tightening (e.g., PG), see document P2280PM.
