The final speed must be lower than the standard speed.
The angle counting starts when the Threshold Torque is reached.
After switching off via the Shut-Off Torque/Shut-Off Angle, the torque that develops or the associated an-
gle is compared with the Minimum/Maximum Torque and the Minimum/Maximum Angle and evaluated
OK/NOK accordingly.
The following parameters can be programmed in the particular FastApp configuration, see chapter 5.7
FastApps menu, page 27.
Speed selection: In the range of the
maximum speed specified in the tool
constants, with validity at the begin-
ning of the sequence up to the thresh-
old torque (mPro mode)/Speed
threshold (FastApps mode).
Begin: With tool start
End:
• T
hreshold Torque (mPro mode)
• Speed threshold (FastApps
Speed when the maximum torque is
reached. Must be less than the start-
ing Speed sein.
FastApps-Modus
As soon as the speed threshold is
reached, the speed is reduced from
the starting speed to the final speed at
the maximum torque. With increasing
torque, the speed drops.
Begin: From the Speed Threshold
Torque
Ende: Shut-Off Torque
Pro mode
In mPro mode, the parameterization
of the controller is valid.
Upper limit of attained angle.
Upper limit of attained torque.
Lower limit of attained angle.
Lower limit of attained torque.
Beginning of angle counting.
Valid monitoring torque during the
tightening process. If the monitoring
torque is exceeded, the drive stops
1
The maximum torque is not normally reached. The torque shutoff value is less than the maximum torque.
Therefore, it is not completely regulated to the final speed.
