COBHAM RT-7000 PMR User Manual

150-071724 Rev N
This document contains proprietary information, see
proprietary statement on first page.
Page 29 of 138
5.4 COMPONENT SPECIFICATIONS
COMPONENT
POWER REQUIREMENTS
RT-7000 PMR
Nominal Input Voltage: 27.5 ±0.5 VDC
Range: 22 to 33 VDC input
Low Operating Power*: 18 to 22 VDC input
Current: TX (normal): 10 amps max
RX (idle): 4 amps typical
RT-7000 RCDU
Nominal Input Voltage: 27.5 ±0.5 VDC
Range: 18 to 33 VDC input
Current: 1 Amp max
RT-7000 RMR
Nominal Input Voltage: 27.5 ±0.5 VDC
Range: 18 to 33 VDC input
Low Operating Power*: 18 to 22 VDC input
Current: TX (normal): 10 amps max
RX (idle): 4 amps typical
Antenna Switching
Unit
Nominal Input Voltage: 27.5 ±0.5 VDC
Range: 18 to 33 VDC input
Current: 110 mA
Antenna Tuner
Nominal Input Voltage: 27.5 ±0.5 VDC
Range: 18 to 33 VDC input
Current: 500 mA
Table 5-1: System Power Requirements
*Voltage below 22V will induce a low power transmission (1W). Low voltage
operation may also affect the audio and transmission performance.
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
