COBHAM RT-7000 PMR User Manual

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 94 of 138
PI
N
SIGNAL NAME
Connection
Wire
Destination
A
Rx Data +
24 TSP
Antenna Port 1 RT-7000 PMR J101-39
Antenna Port 2 RT-7000 PMR J101-56
Antenna Port 3 RT-7000 PMR J101-39
B
Rx Data -
Antenna Port 1 RT-7000 PMR J101-38
Antenna Port 2 RT-7000 PMR J101-19
Antenna Port 3 RT-7000 PMR J101-20
C
Tx Data +
24 TSP
Antenna Port 1 RT-7000 PMR J101-16
Antenna Port 2 RT-7000 PMR J101-58
Antenna Port 3 RT-7000 PMR J101-18
D
Tx Data -
Antenna Port 1 RT-7000 PMR J101-15
Antenna Port 2 RT-7000 PMR J101-59
Antenna Port 3 RT-7000 PMR J101-17
E
S3 Program
22
Antenna Tuner J1-S
F
Reserved
NC
-
-
G
Reserved
NC
-
H
Reserved
NC
-
J
Reserved
NC
-
K
Reserved
NC
-
L
S0 Program
22
Antenna Tuner J1-M
M
SO Program Ground
22
Antenna Tuner J1-L
N
Reserved
NC
-
P
Reserved
NC
-
Q
Reserved
NC
-
R
Reserved
NC
-
S
S3 Program Ground
22
Antenna Tuner J1-L
T
Reserved
NC
-
V
Reserved
NC
-
Table 7-8: Antenna Tuner J1 Signals
(2) J2
The J2 connector provides power and ground signals to the tuner. J2 is a
KPTO2E-8-33P, 3 pin connector, with aircraft mating connector: KPT06E-8-33S
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
