Component
Weight
AT-695
0.5 lbs (.23 kg)
AT-462
0.5 lbs (.23 kg)
AT-400
0.75 lbs max (.34 kg)
Comant CI-295-300
2.00 lbs max (.91 kg)
FC-5000
1.65 lbs. Max. (0.75 kg)
FC-570
1.65 lbs. Max. (0.75 kg)
Antenna Switching Unit
0.35 lbs max (0.16 kg)
APM
.02 lbs (10 g)
Table 6-1: Component Weights
6.4 INSTALLATION OF MULTI-PIN CRIMP CONNECTORS
A. Contacts and Crimp Tool Information
Contacts, D-Sub, Min. Crimp
PN 129-115451-01 Positronic PN
FC8022D, crimp (or equivalent)
Insertion/Removal Tool
M81969/1-04 or equivalent
B. Contacts and Insertion/Removal Tool Manufacturer Name and Address:
Positronic Industries, Inc.
423 N. Campbell Ave.
PO Box 8247
Springfield, Missouri 65801
6.5 INSTALLATION OF RT-7000 PMR
Mount RT-7000 PMR on DZUS/rails per MIL MS-25213.
See Figure 6-1 for mounting dimensions.
6.6 INSTALLATION OF RT-7000 RMR
Mount RT-7000 RMR in single (see Figure 6-2) or dual (see Figure 6-3) mounting rack.
See Figure 6-4 for RT-7000 RMR dimensions.
6.7 INSTALLATION OF RCDU
Mount RCDU on DZUS/rails per MIL MS-25213.
See Figure 6-5 for mounting dimensions.
