5.4.5 TUNING CONVERTERS
5.4.5.1 FC-570 (for use with AT-570)
Requirement
Power Consumption:
≤1000 mA @ 16±0.2 V
dc
≤500 mA @ 32±0.5 V
dc
Ambient Temperature
Range
Normal operation
-55° to +70° C
Altitude
50,000 ft
5.4.5.2 FC-5000 (for use with AT-5000 and AT-560)
Requirement
Power Consumption:
≤850 mA @ 16±0.2 V
dc
≤850 mA @ 32±0.5 V
dc
Ambient Temperature
Range
Normal operation
-55° to +70° C
Altitude
50,000 ft
5.4.6 ANTENNA SWITCHING UNIT
A switch, P/N 130-071622-01 is available to connect the single coax output from each
PMR/RMR transceiver to multiple elements of an antenna or multiple antennas.
Figure 5-14 illustrates a typical switch installation.
