COBHAM RT-7000 PMR User Manual

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 88 of 138
PI
N
SIGNAL NAME
Connection
Wire
Destination
21
Reserved
NC
-
-
22
Reserved
NC
-
-
23
Reserved
NC
-
-
24
Reserved
NC
-
-
25
Reserved
NC
-
-
26
Reserved
NC
-
-
27
Reserved
NC
-
-
28
Reserved
NC
-
-
29
Reserved
NC
-
-
30
Reserved
NC
-
-
31
Reserved
NC
-
-
32
Reserved
NC
-
-
33
Reserved
NC
-
-
34
Reserved
NC
-
-
35
Reserved
NC
-
-
36
Remote Radio
Control TX +
24 TSP
RT-7000 PMR RX+ (J101-54)
37
Remote Radio
Control TX -
RT-7000 PMR RX- (J101-55)
38
Reserved
NC
-
-
39
Reserved
NC
-
-
40
Reserved
NC
-
-
41
Reserved
NC
-
-
42
Reserved
NC
-
-
43
Reserved
NC
-
-
44
Reserved
NC
-
-
45
Reserved
NC
-
-
46
Reserved
NC
-
-
47
Reserved
NC
-
-
48
Reserved
NC
-
-
49
Reserved
NC
-
-
50
Reserved
NC
-
-
51
Reserved
NC
-
-
52
Reserved
NC
-
-
53
NVIS_N
22
Aircraft NVIS switch (Optional)
