COBHAM RT-7000 PMR User Manual

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 97 of 138
Item
Designator
Aircraft Mating Connector
Cobham Installation
Kit
RT-7000 PMR/RMR
System Interface
J101
Positronic P/N ODD78S1000S/AA-14 or
equivalent (ITT Cannon DDMA78SNM).
129-271260-01
Slot 1 RF
J102
TNC for LMR400 Coax:
Straight: Amphenol P/N 122393 or equivalent.
Right Angle: Amphenol P/N 122416 or equivalent
NA
Slot 2 RF
J103
TNC for LMR400 Coax:
Straight: Amphenol P/N 122393 or equivalent.
Right Angle: Amphenol P/N 122416 or equivalent
NA
Slot 3 RF
J104
TNC for LMR400 Coax:
Straight: Amphenol P/N 122393 or equivalent.
Right Angle: Amphenol P/N 122416 or equivalent
NA
Power Connector
J105
Positronic P/N RD9S1000S/AA-14 or equivalent
(ITT Cannon DEMA9SNM)
129-271261-01
Ethernet
J106
Amphenol P/N MAC000112-480 (maintenance
only)
NA
RCDU
System Interface
M2J1
Positronic P/N ODD78S1000S/AA-14 or
equivalent (ITT Cannon DDMA78SNM).
129-271260-01
Power Connector
M2J2
Positronic P/N RD9S1000S/AA-14 or equivalent
(ITT Cannon DEMA9SNM)
129-271261-01
Ethernet
M2J4
Amphenol P/N MAC000112-480 (maintenance
only)
NA
AT-400
Hi-Split RF
J401
N Type for LMR400 Coax
Straight: Amphenol P/N 172345
Right Angle: Amphenol P/N 082-4442
NA
AT-160
Hi-Split RF
J401
TNC for LMR400 Coax:
Straight: Amphenol P/N 122393 or equivalent.
Right Angle: Amphenol P/N 122416 or equivalent
NA
Lo-Split RF
J402
N Type for LMR400 Coax
Straight: Amphenol P/N 172345
Right Angle: Amphenol P/N 082-4442
NA
AT-560/570/5000
Hi-Split
J402
TNC for LMR400 Coax:
Straight: Amphenol P/N 122393 or equivalent.
Right Angle: Amphenol P/N 122416 or equivalent
NA
