Cognex DataMan 50 - Scan Map for Dataman 300 and 360 Series Readers Using a 24 MM Lens with Liquid Lens

The following table shows the Field of View widths in mm at various distances.
Distances in mm DM300, DM360 DM302/303, DM362/363
50 11 17
100 22 34
150 33 52
250 56 86
500 111 172
Scan Map for DataMan 300 and 360 Series Readers Using a 24 mm Lens
with Liquid Lens
The maps in this section show the field of view of the DataMan 300/360, DataMan 302/362, and DataMan 303/363
readers with a 24 mm lens with a liquid lens and DM360-HPIL-RE-01 or DM360-HPIL-RE-P-01 cover.
The FoV values are shown as follows:
l outer: DM303/DM363
l middle: DM302/DM362
l inner: DM300/DM360
The reading distances for the DM300 and DM302 readers are the same. The DM303 and DM363 feature a higher
resolution and more pixels in about the same sensor size.
The following table shows the FoV widths in mm at various distances.
Distances in mm DM300 DM302/DM362 DM303/DM363
80 11 19 20
250 43 68 73
500 87 139 148
1000 175 281 298
136
Optics and Lighting
