DataMan 70 9 Pin Adapter Cable

The following table shows the pinouts.

Pin Number Signal Name

1 Trigger

2 TXD Output TTL Only

3 RXD Input TTL Only

4 NC

5 Ground

6 +5 V Power

7 CTS Input TTL Only

8 RTS Output TTL Only

9 Beeper/Download
