Cognex DataMan 50 - Dataman 50 and 60 Digital Input Lines

This is a female connector/socket.
IN Color Signal
11 Light Blue/Black Output-1
12 Light Blue/Yellow Output-Common
13 Light Blue/Green Output-Strobe
DataMan 50 and 60 Digital Input Lines
Inputs are not galvanic isolated but need to be referenced to ground.
87
Electrical Information
