Mounting Requirements
The DataMan 150, 260, 300, 360, 370, 470, and 503 series readers provide four threaded attachment points, located as
shown in the previous sections:
l DataMan 70 Series Reader Dimensions
l DataMan 150 Series Reader Dimensions
l DataMan 260 Series Reader Dimensions
l DataMan 280 Series Reader Dimensions
l DataMan 300 Series Reader Dimensions
l DataMan 360 Series Reader Dimensions
l DataMan 370 Series Reader Dimensions
l DataMan 470 Series Reader Dimensions
l DataMan 503 Reader Dimensions
The attachment points have the following characteristics:
l M3 thread
l 5 mm thread depth
l 9 N-cm (0.8 Lb-In) maximum torque
CAUTION: Use all four attachment points when mounting your DataMan reader.
Mounting the DataMan 70 Reader
Mounting the DataMan 70 at a slight angle (15°) can reduce reflections and improve reader performance. Having a
recess for screw heads on the top and the bottom, the DataMan 70 allows for upside down mounting. Recommended
fasteners and nuts:
74
Mechanical Information
