DataMan 300 Series Reader Dimensions

1 M3-5 (4x) mounting holes of the device

2 M3-6 (4x) mounting holes for external illumination

3 Illumination lights

4 Operating buttons

5 S-Mount (M12) Lens version

6 C-Mount Lens version

Mechanical Information
