Thermal and Environmental Requirements
See the following table for thermal and environmental requirements:
Operating temperature 0 ºC — 40 ºC (32 ºF — 104 ºF)
Storage temperature -10 ºC — 60 ºC (-14 ºF — 140 ºF)
Maximum humidity 95% (non-condensing)
DataMan 50, 150, 260, 300, 360, and 503 IP Rating
The DataMan 50, 150, 260, 300, 360 series and 503 readers provide IP65 protection against dust and water intrusion. In
order to meet this rating, the following conditions must be met:
l All connectors must have cables connected or be sealed with protective plugs.
l The reader front cover and lens cover must be correctly installed.
l The requirements for temperature, vibration, and shock must be met.
DataMan 60 and 70 IP Rating
The DataMan 60 and 70 readers provide IP40 protection against dust and water intrusion. In order to meet this rating, the
following conditions must be met:
l All connectors must have cables connected or be sealed with protective plugs.
l The reader front cover and lens cover must be correctly installed.
l The requirements for temperature, vibration, and shock must be met.
DataMan 280, 370 and 470 IP Rating
The DataMan 280, 370 and 470 series readers provide IP67 protection against dust and water intrusion. In order to meet
this rating, the following conditions must be met:
83
Mechanical Information
