42
5.3.0 No Devices Detected or Manually Configure the Port
• Check Window’s “Devices and Printers” for the “CI-Bus Hub”.
If it does not exist perform the following procedure:
Exit the Treadmill Software program.
Disconnect the USB cable between the computer and the CI-Bus Hub.
Refer to section: “2.1 CI-Bus Hub Driver Installation” and install the drivers.
Reboot the computer if needed.
Connect the CI-Bus Hub to any available USB port on the computer and wait for Windows to
recognize the device and install the drivers.
Open Window’s “Devices and Printers” and check for the “CI-Bus Hub”. If it doesn’t exist,
try another USB port on the computer. If the CI-Bus Hub cannot be detected, contact
Columbus Instruments for further assistance.
Once detected, close “Devices and Printers” and launch the Treadmill Software.
• Check the CAT5 Networking cable connections
Remove, then fully insert the cables into the CI-Bus ports of the CI-Bus Hub and other
devices.
Be sure there are four (4) orange terminators, one (1) for each port (A, B, C, D) of the CI-Bus
Hub. Each terminator should be placed at the end of the CI-Bus in the available CI-Bus port
of the last device.
Click the Scan Ports button to continue.
• Check the AC power to all devices.
Switch “Off” all devices and wait one minute.
If connected, switch “On” the AC-power to the Treadmill Shock Detection Unit(s) first.
Then switch “On” all other remaining devices (Treadmill and Incline Controllers).
Check them for normal operation and that they respond to button-presses and control
adjustments.
Click the Scan Ports button to continue.
