Compaq Deskpro 2000 Series of Personal Computers 5-37
5.17 Drive Cage
To remove the drive cage from the computer chassis, complete the following steps:
1. Remove the system unit cover (Section 5.6).
2. Remove the front bezel (Section 5.14.1).
3. Remove the three screws that secure the drive cage to the chassis.
4. Slide the drive cage back towards the inside of the chassis to release the latches.
5. Lift the assembly up to remove it from the chassis.
Figure 5-36.
Removing the Drive Cage
To replace the drive cage, reverse the above procedure.
CAUTION:
When replacing the drive cage, be careful that the LED cable does not get caught, pinched,
or otherwise damaged.
