Compaq Deskpro 2000 Series of Personal Computers A-1
appendix
A
C
ONNECTOR
P
IN
A
SSIGNMENTS
This appendix contains the pin assignments for all external connectors:
Table A-1
Keyboard
Connector and Icon (Orange) Pin Signal
6
34
5
21
KEY
1
2
3
4
5
6
Data
Unused
Ground
+5 VDC
Clock
Unused
Table A-2
Mouse
Connector and Icon (Green) Pin Signal
6
34
5
21
KEY
1
2
3
4
5
6
Data
Unused
Ground
+5 VDC
Clock
Unused
