Compaq Deskpro 2000 - Expansion Board

Compaq Deskpro 2000 Series of Personal Computers 5-9
5.8 Expansion Board
The desktop versions of the Compaq Deskpro 2000 Series of Personal Computers have five
expansion slots: three on the outboard side of the riser board and two on the inboard side.
Figure 5-7.
Five Expansion Slots on the Desktop Computer
1 One PCI/ISA expansion slot on the outboard side of the riser board in the uppermost position.
2 Two dedicated ISA expansion slots on the outboard side of the riser board.
3 Two dedicated PCI expansion slots on the inboard side of the riser board.
