Compaq Deskpro 2000 - Jumper Settings

Compaq Deskpro 2000 Series of Personal Computers 7-11
Figure 7-13.
2.1-GB Maxtor EIDE Hard Drive Jumper Settings
Table 7-7
Jumper Settings
Description MA CS WC FR CO
Single J
Primary in dual system J
Secondary in dual system
O
Cable select J
Write cache enabled J
Reserved O
4032 cylinder option enabled J
J = Jumper. O = No jumper.
