Compaq Deskpro 2000 Series of Personal Computers 7-3
Table 7-1
Pentium System Board Connectors, Jumpers, and Switches
Device Description
E6 Power-on password enable/disable header
E8 Clear CMOS header
E9 External (replacement) battery
J6 Cache memory connector
J9 Riser board socket
J10 DIMM #1 socket
J11 DIMM #2 socket
J12 DIMM #3 socket
J1001 Graphics memory upgrade socket (used with J1002)
J1002 Graphics memory upgrade socket (used with J1001)
P1 Power connector
P10 Diskette cable socket
P18 LED socket
P20 Primary IDE/EIDE cable socket
P21 Secondary IDE/EIDE cable socket
P1000 VESA socket
SW1
Processor/bus speed selector
XU1 Microprocessor socket
