Compaq Deskpro 2000 Series of Personal Computers A-5
Table A-9
Line-In Audio Connector
Connector and Icon Pin Signal
1 (Outside)
2 (Inside)
3 (Inside)
Ground
Left Channel Data
Right Channel Data
Table A-10
Line-Out Audio Connector
Connector and Icon Pin Signal
1 (Outside)
2 (Inside)
3 (Inside)
Ground
Left Channel Data
Right Channel Data
Table A-11
Microphone Connector
Connector and Icon (Blue) Pin Signal
1 (Outside)
2 (Inside)
3 (Inside)
Ground
Left Channel Data
not supported
Table A-12
Headphone Connector
Connector and Icon Pin Signal
1 (Outside)
2 (Inside)
3 (Inside)
Ground
Left Channel Data
Right Channel Data
Table A-13
USB Connector
Connector and Icon Pin Signal
1 2 3 4
1
2
3
4
VCC
- Data
+ Data
Ground
