H-2 Intel 44LX Chipset Memory Limitations
Table H-1
SDRAM Memory Technologies
SDRAM
Size
Address
Locations
SDRAM
Width
Number Of Chips Non-ECC
(64 bits)
Number Of Chips ECC
(72 bits)
DIMM
Size
1M×16 1M ×16 4 chips total, 1 side 5 or 6 chips total -1 side 8 MB
1M×16 1M ×16 8 chips total, 4 per side 10 or 12 chips total, 5 or 6 per side 16 MB
2M×8 2M ×8 8 chips total , 1 side 9 chips total , 1 side 16 MB
2M×8 2M ×8 16 chips total, 8 per side 18 chips total, 9 per side 32 MB
4M×4 4M ×4 16 chips total , 1 side 18 chips total, 1 side 32 MB
4M×4 4M ×4 32 chips total, 16 per side 36 chips total, 18 per side 64 MB
4M×16 4M ×16 4 chips total, 1 side 5 or 6 chips total, 1 side 32 MB
4M×16 4M ×16 8 chips total, 4 per side 10 or 12 chips total, 5 or 6 per side 64 MB
8M×8 8M ×8 8 chips total , 1 side 9 chips total , 1 side 64 MB
8M×8 8M ×8 16 chips total, 8 per side 18 chips total, 9 per side 128 MB
16M×4 16M ×4 16 chips total , 1 side 18 chips total, 1 side 128 MB
16M×4 16M ×4 32 chips total, 16 per side 36 chips total, 18 per side 256 MB
Note:
This information is intended to be used as a guide to identifying the memory technology used for SDRAM DIMMs and
may not include all technologies. Some of the configurations may not exist in the marketplace.
For example, a 32-MB DIMM with 8 chips per side for 16 chips total is most likely comprised of
16 Mb (2M×8) technology SDRAMs giving a data width of ×8.
That same 32-MB DIMM with only 4 chips on one side is most likely comprised of 64 Mb (4M×16)
technology SDRAMs with a data width of ×16.
