Table 1-8
Rear Panel Connectors
Ref. Component Function
1 Voltage Select Switch Switches voltage between 115 V (U.S.) and 230 V to meet geographical requirements.
2 Serial Connector Connects a serial device, such as a serial printer.
3 Parallel Connector Connects a parallel device, such as a parallel printer.
4 Keyboard Connector Connects the keyboard.
5 Mouse Connector Connects the mouse.
6 Universal Serial Bus Connector Connects the computer to any peripheral while the computer is operating. Is a fully
functional Plug and Play connector.
7 Monitor Connector Connects a monitor to an embedded graphics controller.
8 Power Cord Connector Connects the computer to an electrical power outlet.
9 Microphone Connector* Connects a microphone for recording sound and voice.
: Line-In Audio Connector* Connects an external audio input device.
; Line-Out Audio Connector* Connects an external audio output device, such as powered speakers, or a cassette
tape recorder.
< Headphone Connector* Connects headphones (not suitable for unpowered speakers).
* Audio features are available on select models only.
