Compaq Deskpro 2000 Series of Personal Computers 3-21

Figure 3-12.

Miscellaneous Plastics Kit, Minitowers

Table 3-10

Miscellaneous Plastics Kit, Minitowers

Description Spare Part Number Warranty Tier

Miscellaneous plastics kit, includes:

1. Bezel blank, 1/2 height (1 each)

2. Spring (1 each)

3. Power button (2 each: 1 DC, 1 AC)

4. Retainer, ISA Option Board (1 each)

5. Air duct (for Pentium II minitower systems only)

6. Guide, Option Card (1 each)

7. Rubber feet (4 each)

8. AC/DC switch cap RTF card*

243107-001 D

* Not shown.
