Compaq Deskpro 2000 Series of Personal Computers 3-23
Figure 3-14.
Miscellaneous Parts
Table 3-12
Miscellaneous Parts
Description Spare Part Number Warranty Tier
1. Two-button mouse 141189-401 A
2. Battery, real-time clock (external) 160274-001 A
3. Heat sink, Pentium processor (w/ 2 thermal pads) 243128-001 D
4. Speaker, 2.5-in, 0.6 W (audio option kit) 247508-001 D
5. Microphone assembly w/ base (audio option kit) 278266-001 D
6. Security lock bracket with screw 173066-001 D
7. Bracket board retainer 268247-001 A
8. Diskette drive mounting bracket, 3.5-in to 5.25-in 243230-001 D
9. Hard drive mounting bracket, 3.5-in to 5.25-in 243231-001 D
10.
Multi-media sound system (U.S.)*
294122-001 D
11.
Heat sink, Pentium II processor (w/ 1 thermal pad)*
278264-001 D
* Not shown.
