Explanation of the display positions
Text displays during boot screen after switching on and restarting the SAM.
Serial number of the meter
Day of manufacture (day of programming)
Number of charging processes that are still possible and can be saved.
Text displays during operation of the charging column.
The current date and time are permanently displayed in the first line. The date
is displayed in the format dd.mm.yyyy, the time is displayed in the format
hh:mm:ss.
The initial value represents the meter reading at the beginning of a specific
charging process. It is displayed during a charging process and also when a
completed charging process is displayed. The display is in kilowatt hours.
The final value is displayed after finishing and when retrieving a finished
charging process. The display is in kilowatt hours.
Difference between the initial value and the actual value. After completion of
the charging process, it is the difference between the start and final value
(power extracted). The display is in kilowatt hours.
At this point, the start time of the charging process is recorded. Both the date
and the time are relevant here.
At this point, the end time of the charging process is recorded. Both the date
and the time are relevant here.
Time from the start of the charging process to the current time. When charging
is complete, the total time from start to finish is displayed. The duration is
displayed in the format hh:mm:ss ss or, from a duration of 1 day, in the format
dd:hh:mm.
The user ID used for authorisation is shown here. During the charging process,
this cannot be recognised except for a few leading digits.
- Delivery point has a type 2 plug.
- Delivery point has a CCS plug.
- Delivery point has a CHAdeMO plug.
To Next Page
