Installation
2023-05 D111XXXXXX | 05 57
5.8.1 BM installation
The installation site must be chosen so that the cables do not protrude onto the road and do not come
to rest between the kerb and the road.
Installation sequence
1. Select a suitable installation site.
2. Check ground for stability.
3. Check parts and installation material for completeness.
4. Measure and drill fixing holes on the ground.
5. Insert ground anchorage.
7. Place the CMS on the ground anchorage and screw it in place.
5.8.2 Inserting the ground anchorage
The design of the ground anchorage must be adapted to the subsoil condition and/or special local
conditions.
The following description of the assembly is therefore only exemplary. Local conditions are not dealt
with in detail. Deviating procedures may only be initiated by competent persons.
Installation requirements
• Ground conditions with sufficient load-bearing capacity and evenness. In case of doubt, a
qualified civil engineering company must establish the ground conditions and carry out the
installation
Installation material and tools
• Depending on ground conditions, 4 suitable ground anchors (e.g. expansion or injection anchors)
with threaded bolt M10 or internal thread M10 (not in scope of delivery)
• Suitable drilling tool
