Product description
26 D111XXXXXX | 05 2023-05
3.5.3 1 x DC charger interface and 1 x AC charger interface (2 in 1)
General information
Charging system
Cito BM 500
Charging mode
Mode 3/ IEC 61851
DC charger interface:
1 x CCS plug with attached cable
or
1 x CHAdeMO plug with attached cable
AC charger interface:
1x type 2 socket (sliding or folding)
Connections
Mains connection
Main switch + PE terminal + PA rail
Connection cross-section
min 50 mm²
Data line
Cable connection
Min. connection cross-
section
26 AWG
Max. length
30 m
Electrical characteristics
Max. DC charging capacity
per charging point
50 kW
Max. AC charging capacity
per charging point
22 kW
DC charging voltage
200 – 480 V/ 1-
AC charging voltage
400 V/ 3~
DC charging current
max. 125 A
AC charging current
32 A
Mains voltage
400 V/ 3~
Max. rated current
112 A/ 3~
Mains frequency
50 Hz
