5 Technical data
Unless otherwise stated, the technical specifications are the same for all unit types.
5.1 Measuring capsule
Ambient conditions
Specification
Value
Unit
Approved installation site
Internal spaces or
at least IP34 protected area
Temperature range
-25 - +70
°C
Humidity
≤ 95
%
Mechanical/EMC requirement class:
M1/E2
Technical data of the SAM nominal operating conditions
Specification
Value
Unit
Supply voltage
12
V
Power consumption
≤ 0.7
W
Protection class (housing)
IP 54
Limit current Imax
≤ 60
mA
Range power factor cos φ during the
charging process
0.9 - 1
Electromagnetic environmental
conditions
Testing was carried out according to DIN EN 50470
Technical data of the meter nominal operating conditions
Specification
Value AC
Unit
Reference frequency (fn)
50
Hz
Reference voltage
4-wire meter: 3 x 230/400
2-wire meter: 230 V at L3
V
Reference current Iref
5
A
Limit current Imax
60
A
Actual starting current
10
mA
Minimum current Imin
100
mA
Transient current It
500
mA
Meter constant
IR LED output with 10,000
Imp/kWh
Terminals - Ø
8 terminals each with Ø 6.5
Screws 2 x M6 per terminal
mm
Protection class
II
Protection class (housing)
IP 54
Power consumption
Current path: ≤ 1,1 W at 60A
Voltage path: ≤ 0.7 W/ 2 VA
Auxiliary voltage
-
5.2 Accuracy of the charging equipment
The accuracy of the charging equipment at the delivery point corresponds to that of an electricity meter of MID
class A at nominal operating conditions.
