Installation
2023-05 D111XXXXXX | 05 37
5 Installation
Incorrect installation can lead to personal injury and damage to property. It must be ensured that the
assembly and electrical installation are carried out professionally and that the local protective
measures and the specifications of the energy supplier are observed.
The charging systems may therefore only be installed by a qualified electrician and persons who are
demonstrably qualified.
5.1 Location
For professional installation, safe operation and barrier-free access to the charging system, the
following points must be observed when selecting the location.
• National or local regulations.
• Do not install the charging system in the hazard areas of:
– Flammable, combustible and explosive materials
– Running or jet water
• Do not install the charging system in the following areas:
– Areas that are potentially explosive (e.g. gas filling stations)
– Areas where backwater or storm water is to be expected
– Areas where flooding is to be expected
– Areas where heat domes or heat accumulation can occur
• The substrate must have sufficient strength and load-bearing capacity to withstand the
mechanical loads.
• Provide sufficient space to maintain the minimum distances:
– Approx. 120 cm between two charging systems
– 3 cm from the back of the charging system to other objects; on a concrete base in the
case of a mechanical installation
• Ensure a sufficient fresh air supply for cooling the charging system and heat dissipation.
• Observe ambient conditions, see Technical Data.
• - Ensure stable LTE connection. If necessary, switch to LAN or external LTE antenna. It is
recommended to install a duplex network cable (CAT 7).
