Installation

46 D111XXXXXX | 05 2023-05

5.4.3 Base plate

A base plate is installed inside the charging

system. The base plate serves among other things

as strain relief.

NOTE

The base plate must be mounted.

Otherwise the operation of the charging

system may be limited.

Fig. 19: Base plate

NOTE

To protect the charging system, we recommend to install an approach limiter (e.g. bollard).
