7. WARNING – Crushing of body parts due
to unintentional lowering. Body parts must
not be under lifted load.
Position and align the charging system over
the drilled holes so that the mounting holes
of the charging system match the mounting
holes in the concrete base.
8. Insert the power supply cable through the
cable gland of the base plate into the
charging system.
9. Fasten the charging system to the concrete
base with four screws (M 10 x 50).
– The installation material is included
in the scope of delivery.
