Operation
2023-05 D111XXXXXX | 05 85
97
The charging system indicates the "Type 2 Finish with entry +
Code: + * = Delete + # = Cancel" state.
The charging process at the corresponding charger interface
is in progress. The charging process can be finished by
entering the code.
98
The charging system indicates the "CCS Plug in plug correctly"
state.
The plug of the corresponding charger interface should be
correctly plugged into the charging system.
99
The charging system indicates the "CHA Plug in plug correctly"
state.
The plug of the corresponding charger interface should be
correctly plugged into the charging system.
100
The charging system indicates the "Type 2 Plug in plug correctly"
state.
The plug of the corresponding charger interface should be
correctly plugged into the charging system.
101
The charging system indicates the "CCS - Unplug the plug and plug
in again" state.
The plug of the corresponding charger interface should be
unplugged from the charging system and plugged in again.
102
The charging system indicates the "CHA - Unplug the plug and plug
in again" state.
The plug of the corresponding charger interface should be
unplugged from the charging system and plugged in again.
103
The charging system indicates the "Type 2 - Unplug the plug and
plug in again" state.
The plug of the corresponding charger interface should be
unplugged from the charging system and plugged in again.
104
The charging system indicates the “Preparing charging process
+ Stage:" state.
The charging process is in preparation and will start soon.
