Finally, set the asynchronous character format. Use the   keys to select the
parameter, and then use the  keys to select the format. The available
choices (i.e., number of data bits; odd, even, or no parity; number of stop bits) are
8-N-1, 7-E-2, or 7-O-2. Press ENTER.
6.2.3.2.3 (REMOTE:) ETHERNET
The DT-4500 Series C- and Ku-Band Down Converters, as initially
released, do not feature a rear panel ‘Ethernet’ port. Only current
production units offer Ethernet Interface operation. See Chapter 4.
FRONT AND REAR PANEL CONNECTORS for more information.
ADDRESS GATEWAY SNMP
MAC = 00-06-B0-00-00-0F
On the top line, use the   keys to select ADDRESS, GATEWAY, or SNMP. The
bottom line displays the read-only unit MAC address. Press ENTER.
6.2.3.2.3.1 (REMOTE:) ETHERNETADDRESS
IP Address/Range:
192.168.001.002/24
Edit the Management IP Address and Range for the rear panel ‘Ethernet’
100BaseTX port. Use the   keys to select a digit, and then use the  keys
to change that digit. Press ENTER.
6.2.3.2.3.2 (REMOTE:) ETHERNETGATEWAY
Ethernet IP Gateway:
192.168.001.002
Edit the IP Gateway Address for the rear panel ‘Ethernet’ 100BaseTX port. Use
the   keys to select a digit, and then use the  keys to change that digit.
Press ENTER.
