Comtech EF Data DT-4500 Series - PSM (Polarity Switch Module) Assemblies; TSM (Transmit Switch Module) Assemblies; EQM (Equalizer Module) Assemblies

DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Specifications Revision 2
2–5
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-21 50 UT-4518 w/Isolator, Type ‘SMA’
AS/0101-23 75 UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-29 50 UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-39 50 DT-451X w/Isolator, Type ‘SMA’
AS/0101-40
75
DT-451X w/Isolator, Type ‘SMA’
2.1.8.5.2 PSM (Polarity Switch Module) Assemblies
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-10
75
DT-4503, DT-4572, UT-4579 Switching, Type ‘N’
AS/0101-11
75
DT-4503 Switching, Type ‘SMA’
AS/0101-24
50
DT-4572, UT-4579 RF Switching, Type ‘N’
AS/0101-30
50
Type ‘SMA’
AS/0101-35
50
DT-451X w/Isolator, Type ‘SMA’
AS/0101-36
75
DT-451X w/Isolator, Type ‘SMA’
2.1.8.5.3 TSM (Transmit Switch Module) Assemblies
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-3
75
DT-4503, UT-4505 Switching, Up, Type ‘SMA’
AS/0101-5 75 DT-4503, DT-4572, UT-4505, UT-4579 Switching, Up, Type ‘N’
AS/0101-8 50 DT-4503, DT-4572, UT-4505, UT-4579 Switching, Up, Type ‘N’
AS/0101-17 50 DT-4503, UT-4505 Switching, IF & RF, Type ‘SMA’
AS/0101-18 75 UT-4518 Switching IF & RF w/Isolator, Type ‘SMA’
AS/0101-22 75 UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-27 50 UT-4514/F w/Isolator, Type ‘SMA’
AS/0101-28 50 UT-4518 w/Isolator, Type ‘SMA’
AS/0101-42 75 DT-451X w/Isolator, Type ‘SMA’
AS/0101-43
50
DT-451X, UT-4514/F w/Isolator
2.1.8.5.4 EQM (Equalizer Module) Assemblies
CEFD P/N
Impedance
(Ohms)
Comments
AS/0101-13 75
DT-4503, DT-451X, DT-4572, UT-4505, UT-4579 EQM for 1:1,
Type ‘SMA’
AS/0101-25 50
DT-4503, DT-451X, DT-4572, UT-4505, UT-4579 1:N IF & RF
Switch, Type ‘SMA’
