DT-4500 Series C- and Ku-Band Down Converters MN/DT4500.IOM
Specifications Revision 2
2–9
2.2.8.5 Intermodulation
-60 dBc @ 0 dBm Output SCL
2.2.8.6 Impedance
50Ω or 75Ω
2.2.8.7 Return Loss
23 dB minimum with RF/IF Connector or Switch Module
2.2.9 Transfer
2.2.9.1 Gain
45 dB ±2 dB
2.2.9.2 Attenuation Adjustment
• STANDARD: 0 to 20 dB in 0.25 dB Steps
• OPTIONAL: 0 to 20 dB in 0.1 dB Steps
2.2.9.3 Gain Stability
± 0.25 dB/day
2.2.9.4 Ripple
Contact Comtech EF Data Product Support for your specific requirements.
• ±0.25 dB (±18 MHz) – OPTIONAL ±20 MHz
• 0.75 dB (±36 MHz) – OPTIONAL ±40 MHz
